1/0 AWG Lead Wire Type MG UL 5107 – Nickel Clad Copper – Glass Reinforced Mica Tape 450C UL/538C Non-UL – 600V – Tan – Cut To Length

Description

1/0 AWG Lead Wire Type MG UL 5107 – Stranded Nickel Clad Copper 259 STR – Glass Reinforced Mica Tape Insulation 450C UL/538C Non-UL – 600V – Tan – Cut To Length
AWG Size:1/0
Cable Type:Type MG
Color:Tan
Conductor:Nickel Clad Copper
Conductor Stranding:259
Insulation:Glass Reinforced Mica Tape
Jacket:Fiberglass Braid
Lbs./M:400
Length:Cut to Length
No of Conductors:1
Nom. Insulation Thickness:.035 Inches
Nom. O.D.:.535 Inches
Product Family:Industrial Cable
Product Type:Lead Wire
Solid/Stranded:Stranded
Temp. Rating:450C UL/538C Non-UL
Type:UL 5107
UL:5107
Voltage:600V
