16 AWG 8 Pair Type KX Individual & Overall Shielded Thermocouple Extension Cable – 105C – 300V – Yellow – Cut to Length

Description

16 AWG 8 Pair Type KX Thermocouple Extension Cable Solid Chromel-Alumel Conductor – PVC Insulation FR PVC Jacket – Polyester Backed Aluminum Tape Individual & Overall Shielded – PLTC Rated – 105C – 300V – Yellow
AWG Size:16
Cable Type:PLTC
Color:Yellow
Conductor:Chromel-Alumel
Conductor Stranding:1
Construction:Pair
Insulation:PVC
Jacket:FR PVC
Lbs./M:299
Length:Cut to Length
No of Conductors:16
Nom. Insulation Thickness:.016 Inches
Nom. O.D.:.710 Inches
Pairs:8
Product Family:Industrial Cable
Product Type:Thermocouple Extension Cable
Shield Material:Polyester Backed Aluminum Tape
Shielded:Y
Shielding:Individual & Overall Shielded
Solid/Stranded:Solid
Temp. Rating:105C
Type:KX
Voltage:300V
