Leviton MDS15-IDG LEVLOK PIR WALLBOX GRY

Description

Lev-Lok PIR Wall Switch Occupancy Sensor with Self-Adaptive Technology – Gray
Adjustment:Self-Adjusting
Code Compliance:California Title 24
Color:Gray
Contact Type:Relay
Coverage Range Sq. Ft.:2100
Depth:1.75 Inch
Design:Decora Style
Device Type:Occupancy Sensor
Feature:Lev-Lock Wired
Grade:Commercial
Ground:Required
HP Rating:1/4 HP @ 120V
Input Voltage:120/277VAC
LED Color:Red
LED Indicators:PIR Detection
Length:4.06 Inch
Load Rating:1800W@120V INC 1800VA@120V 4000VA@277V FL
Load Type:All
Major Motion:60X35
Major Sq Ft:2100
Minor Motion:30X15
Minor Sq Ft:450
Mounting Height:36 – 54 Inch
Mounting Type:Wall Switch
Neutral:Not Required
Pattern Degrees:180
Photo Cell:Ambient Override ON
Product Family:Lev-Lok
Product Line:Occupancy Sensors
Sensor Technology:Passive Infrared
Sensor Type:PIR
Standards and Certifications:UL/CSA/NOM
Switch Type:Auto/Manual-ON/Auto-OFF
Time Adjustment:30s-30m
Type:Single-Pole Multi-Location
Wallplate:Order Separately
Warranty:5-Year Limited
Width:1.75 Inch
